MPO-MPO Female-to-Male Jumper

Description

MPO-MPO Female-to-Male Jumper

The MPO-MPO Female-to-Male Jumper is a passive optical interconnect assembly designed for parallel optical transceiver AOC modules. It pairs an MPO female connector (no guide pins) with an MPO male connector (with guide pins), supporting polarity identification for high-density data center cabling.

Compatible with QSFP, QSFP28, QSFP-DD, OSFP, Micro QSFP, CXP, CFP, and CDFP AOC modules, this jumper enables passive coupling via 0° and 8° guide pins and lens array assemblies across Ethernet, Infiniband, Fibre Channel, and other network architectures.

Key Features

• Broad transceiver compatibility: Designed for QSFP, QSFP28, QSFP-DD, OSFP, Micro QSFP, CXP, CFP, and CDFP AOC modules.
• Male-female pairing: MPO female (no guide pins) on one end and MPO male (with 2 guide pins) on the other — simplifies polarity management.
• Passive coupling: 0° and 8° coupling via guide pins and lens array assemblies — no active components required.
• Multi-network support: Ethernet, Infiniband, Fibre Channel, and other parallel optical network architectures.
• Multiple fiber grades: OM2 and OM3 multimode fiber available.

Typical Applications

• Hyperscale data centers: 40G / 100G / 400G / 800G parallel optics networks with managed polarity.
• High-density parallel optics: Cabling between MPO/MTP cassettes, transceivers, and patch panels.
• Optical backplane interconnects: Equipment-internal AOC module connections.
• Polarity-managed MPO cabling: Type A / Type B / Type C polarity implementations in MPO trunk systems.

Specifications

Item	Specification
Connector A	MPO Female (no guide pins)
Connector B	MPO Male (with 2 guide pins)
Fiber Shape	Ribbon / Loose tube
Fiber Count	8F / 12F / 16F / 24F
Fiber Grade	OM2 / OM3
Length	20–50 mm (customizable)
Length Tolerance	0.3 mm to 0.5 mm
