8 Port OptiTap Fiber MST Box Terminal Box
Opti Tap

8 Port OptiTap Fiber MST Box Terminal Box

Inquire Online

  • Check Mark Satisfaction guarantee
  • Check Mark Fast delivery
  • Check Mark Quality assurance
Category:

Description

MST Multiport Fiber Terminal, Single-Tube Gel-Filled Cable, Toneable, Stubbed Tail, 8 port

Product Description

ZTO Cable Multiport Service Terminal (MST) Box is designed for FTTx-ODN network access points, providing a pre-connected solution that eliminates the need for closure opening and fiber splicing. Each port comes with hardened adapters, allowing operators to deploy the network efficiently without splicing fibers or opening boxes.

Compared with traditional products, the MST box is easy to operate, highly compatible, and can reduce the Total Cost of Operation (TCO) by 15–30%. It supports multiple installation methods, including wall-mounting, aerial suspension, and pole mounting, adapting to various deployment scenarios.

Built for outdoor use, the MST box is ideal not only for FTTH applications but also for FTTA and other harsh environments, ensuring reliable performance and long-term durability.

Features

  • Factory terminated for high performance;
  • Plug and play adapter ports, fully compatible with Optitap and H-connector;
  • 2, 4, 6, 8, 10, 12, 16 18 ports are available;
  • Stub pigtail length from 10 ft to 1750 ft available;
  • SST, ROC or 5.0mm round input stub cables；
  • Pole, pedestal, handhole, or strand mounting options；
  • IP-68 waterproof protection.

Specification

Product name Multiport Service Terminal, 8 port, Single-Tube Gel-Filled Cable, Toneable, Stubbed
Cable Type Toneable (Dielectric available)
Cable diameter 4.5mm*9.7mm toneable
Installation Pole, pedestal, handhole, or strand mounting options
Stub length 50, 100, 200, 250, 500, 750, 1000, 1250, 1500, 1750, and 2000 feet (additional lengths available)
Specifications – Hardened adapter
Reflectance, Typical -65 dB
Insertion Loss, Typical ≤ 0.15 dB
Adapter Type SC/APC Hardened adapter, compatible with Corning Optitap and H-connector
Optical Characteristics
Fiber Type Single-mode
Fiber count 8F
Fiber Category G.652D
Wavelengths 1310 nm / 1550 nm
Maximum Attenuation 0.35 dB/km / 0.25 dB/km

Application

  • FTTH;
  • Outdoor Areas;
  • Harsh Environment.
