12-Fibers Singlemode 9/125 OS2 LSZH Indoor Ribbon Fiber Optic Cable

Description

12-Fibers Singlemode 9/125 OS2 LSZH Indoor Ribbon Fiber Optic Cable

Factory-fabricated 12-fiber singlemode indoor ribbon fiber optic cable designed for high-density data center backbone and ODF equipment room interconnects. The cable stacks twelve 9/125 µm bend-insensitive G.657.A1 fibers in a flat ribbon stack under LSZH jacket, ready for mass-fusion splicing with 12-fiber ribbon splicers or pre-terminated MPO/MTP connectors. Yellow jacket follows TIA-598-D OS2 color code, and the cable is fully compliant with IEC 60332-3, IEC 60793, and Telcordia GR-409-CORE indoor cable standards.

Key Features

• 12-fiber ribbon stack: mass-fusion splices in 1 minute vs 12 individual splices, ideal for high-density data center backbone builds.
• Bend-insensitive OS2 fiber (G.657.A1): 7.5 mm minimum bend radius for tight routing inside cable trays and ODF frames.
• LSZH yellow jacket: flame-retardant OFNR-rated, low-smoke zero-halogen compliant with IEC 60332-3 for plenum and equipment-room use.
• High-density scalability: stackable from 12 fibers up to 864 fibers by ribbon stacking (24/48/72/96/144/288/432/576/864 cores available on request).
• Pre-terminated options: ships on reel or pre-terminated with MPO/MTP connectors (Base-8/Base-12) at one or both ends.
• Standards compliant: IEC 60793-2-50 B1.1 (OS2 singlemode), IEC 60794-1-2, Telcordia GR-409-CORE indoor.

Applications

• Data center backbone interconnects between ODF frames and equipment rooms
• Hyperscale spine-leaf and intra-building fiber runs
• Mass-fusion splicing for high-density distribution frames
• Pre-terminated MPO/MTP trunk cable raw material (12-fiber ribbon based)
• Central office and telecom equipment room fiber distribution
• FTTH feeder and riser backbone cables in MDU/MTU deployments

Product Structure

Component	Specification
Fiber type	Singlemode 9/125 µm OS2, G.657.A1 bend-insensitive
Fiber count	12 (Base-12 ribbon stack)
Ribbon stack design	1 × 12-fiber ribbon stack (single layer)
Strength member	Aramid yarn (Kevlar) for tensile strength
Inner jacket	LSZH compound, yellow (OS2 standard)
Outer jacket	LSZH, yellow, OFNR-rated, 1.8 mm × 4.5 mm flat
Cable dimensions	1.8 mm × 4.5 mm flat ribbon (12F single layer)
Bend radius (static)	30 mm
Bend radius (dynamic)	60 mm
Operating temperature	-20 °C to +70 °C

Technical Specifications

Cable Construction

Parameter	Value
Fiber count	12 (Base-12, single ribbon stack)
Fiber mode	Singlemode 9/125 µm OS2, G.657.A1
Cable type	Indoor flat ribbon cable
Cable dimensions	1.8 mm × 4.5 mm
Jacket material	LSZH (Low Smoke Zero Halogen), OFNR
Jacket color	Yellow (TIA-598-D OS2)
Strength member	Aramid yarn (Kevlar)
Minimum bend radius (static)	30 mm
Minimum bend radius (dynamic)	60 mm
Tensile load (long term)	200 N
Crush resistance	1000 N/100 mm

Optical Characteristics

Parameter	Value
Attenuation at 1310 nm	≤ 0.40 dB/km
Attenuation at 1550 nm	≤ 0.30 dB/km
Attenuation at 1625 nm	≤ 0.40 dB/km
Mode field diameter @ 1310 nm	9.2 ± 0.4 µm
Cutoff wavelength (cabled)	≤ 1260 nm
Zero dispersion wavelength	1310 ± 10 nm
Zero dispersion slope	≤ 0.092 ps/(nm²·km)
PMD (Polarization Mode Dispersion)	≤ 0.2 ps/√km
Macrobend loss (1 turn @ 15 mm radius, 1550 nm)	≤ 0.05 dB
Macrobend loss (1 turn @ 15 mm radius, 1625 nm)	≤ 0.10 dB

Mechanical & Environmental

Parameter	Value
Operating temperature	-20 °C to +70 °C
Storage temperature	-40 °C to +85 °C
Flame retardant	IEC 60332-3 compliant, OFNR-rated
Smoke density	IEC 61034 compliant
Halogen content	IEC 60754-1 compliant (zero halogen)
RoHS / REACH	Compliant
Standards	IEC 60793-2-50 B1.1, IEC 60794-1-2, Telcordia GR-409-CORE

Available Fiber Counts (Custom Order)

Fiber Count	Ribbon Stack	Typical Outer Dimension (mm)	Application
12	1 × 12F	1.8 × 4.5	Mass-fusion splicing, MPO-12 trunks
24	2 × 12F	2.0 × 5.0	Higher-density MPO trunks
48	4 × 12F	2.4 × 7.0	Backbone distribution
72	6 × 12F	2.8 × 9.0	High-density backbone
96	8 × 12F	3.2 × 11.0	Data center backbone
144	12 × 12F	3.6 × 14.5	Hyperscale backbone
288	24 × 12F	5.0 × 17.0	High-fiber-count distribution
432	36 × 12F	5.5 × 19.5	Very high density
576	48 × 12F	6.0 × 22.0	Maximum ribbon density
864	72 × 12F	7.5 × 28.0	Hyperscale spine-tier

Standard stock: 12 fibers. Fiber counts above 12 available on custom order with minimum order quantity 500 m. Each reel ships with factory test report (attenuation, length, mass-fusion splice compatibility).
